Project Info
Client
Kamco Co
Status
Completed
Location
Amiral Jubail Industrial Complex, Eastern Province, Saudi Arabia
Contractor
Kamco Co
Project Value
SAR 2.3 Million
Project Duration
3 months
Completion Date
November 2023
Project Overview
The L.V Cable Termination project was a specialized electrical infrastructure initiative carried out by El-Masa El Zahabia for Kamco Co at the Amiral Jubail industrial facility. This project focused on the precise termination and connection of low-voltage power cables to ensure safe, reliable, and efficient electrical distribution throughout the facility. Our team’s expertise in electrical systems and strict adherence to international standards were key factors in the successful execution of this technically demanding project.
Scope of Work
The project encompassed comprehensive low-voltage cable termination services, including:
- Cable Preparation: Proper measuring, cutting, and preparation of cable ends
- Termination Installation: Installation of cable lugs, glands, and connectors
- Panel Connections: Termination of cables to distribution panels, switchgear, and control systems
- Testing & Commissioning: Comprehensive testing of all terminations for continuity, insulation resistance, and proper connection
- Documentation: Detailed documentation of all terminations with identification tagging and as-built drawings
- Quality Assurance: Implementation of rigorous quality control measures throughout the process
Technical Details
Cable Specifications
- Cable Types: XLPE/PVC insulated copper cables
- Voltage Ratings: 600/1000V
- Cable Sizes: Ranging from 1.5mm² to 400mm²
- Total Cable Length: Approximately 25,000 meters
- Number of Terminations: Over 3,200 termination points
Termination Methods
- Compression Lugs: Hydraulic crimping for larger cables
- Mechanical Connectors: For medium-sized cables
- Spring-Loaded Terminals: For control and instrumentation cables
- Heat-Shrink Technology: Applied for environmental protection and insulation
Standards Compliance
- IEC 60502: International standard for power cables
- IEEE 48: Standard for cable terminations
- Saudi Electricity Company (SEC) specifications
- Kamco Co internal technical standards
- Saudi Building Code electrical requirements
Quality Control Measures
- Pre-Termination Testing: Cable integrity verification before termination
- Visual Inspection: 100% visual inspection of all terminations
- Pull Testing: Mechanical testing of crimped connections
- Electrical Testing: Insulation resistance, continuity, and polarity testing
- Thermal Imaging: Infrared scanning of connections under load
- Documentation: Detailed records of test results for each termination
